Product Overview

Allen-Bradley designed the 1763-NC01 communication cable for MicroLogix 1100 systems. This cable links Channel 0 to an RS-485 connection. It supports various industrial protocols. The cable length is 30 centimeters. It features an 8-pin Mini-DIN connector and a 6-pin terminal block. This design fits compact automation setups.

The 1763-NC01 enables RS-485 interfacing. It works with DH-485 communication. It also supports Modbus RTU master and slave networks. DF1 half-duplex master and slave modes are available. This versatility suits many system architectures.

The cable meets Class I Division 2 safety standards. It operates safely in hazardous environments. This makes it ideal for industrial operations with strict requirements.

Application Scenarios

Use this cable in factory automation systems. It connects MicroLogix 1100 PLCs to RS-485 networks. Typical applications include conveyor control and machine monitoring. It supports Modbus RTU for data exchange with sensors. DF1 half-duplex works for peer-to-peer communication. The cable also fits Class I Division 2 areas. These include chemical plants and oil refineries.

The 30 cm length reduces cable clutter. It fits inside control panels easily. The Mini-DIN and terminal block connectors ensure secure links.

Technical Specifications

Below are the key specifications from the manufacturer.

• Part Number: 1763-NC01
• Manufacturer: Allen-Bradley
• Series: MicroLogix 1100
• Length: 30 Centimeters
• Connector 1: 8-Pin Mini-DIN
• Connector 2: 6-Pin Terminal Block
• Interface: RS-485
• Compatibility: MicroLogix 1100 Systems
• Protocols: DH-485, Modbus RTU Master, Modbus RTU Slave, DF1 Half-Duplex Master, DF1 Half-Duplex Slave
• Safety Rating: Class I Division 2

These specifications ensure reliable performance in automation tasks.

Installation & Maintenance Guide

Follow these steps to install the cable. First, power down the PLC and connected devices. Then connect the 8-pin Mini-DIN plug to Channel 0. Next, attach the 6-pin terminal block to the RS-485 device. Secure the connections with screws. Avoid bending the cable sharply. Do not exceed the cable length rating. Test communication after installation. No special maintenance is required. Keep connectors clean and dry. Check for damage periodically.

Packing List

The package includes one Allen-Bradley 1763-NC01 communication cable. No additional accessories are included. For shipping, we use FedEx, UPS, or DHL.
